The SPL-X subwoofer always provides the decisive low-frequency foundation in the system – and is immediately ready for use thanks to numerous presets. Thanks to XLR and RCA as well as high-level inputs, the SPL-X can be seamlessly integrated into any audio environment. Whether in the studio, home theater or living room: you can rely on the bass of the SPL-X series.
The high-end subwoofer series combines pioneering DSP technology, a powerful Class D power amplifier and carbon drivers with a fully parametric 6-band EQ. The automatic room calibration ensures linear, rich bass in every room and avoids distortion.
The SPL-X subwoofers deliver pure performance right down into the frequency range – with up to 1800 watts RMS and massive 4-inch voice coils on the larger models. The flagship drivers with dual-spider suspension and vented baskets guarantee maximum control, even at extreme levels. The volume, crossover frequency, phase and EQ can be conveniently controlled from the listening position via the free app.
are the result of decades of research into uncompromising low frequency sound. With the best features, smart operation and massive sound power, they are rightly at the top of the Velodyne Acoustics product world.
| Woofer | 10″ high-performance driver, basket with three ventilation channels, carbon fiber cone, dual-spider Four-layer 3″/76mm voice coil Triple ferrite magnet system |
|---|---|
| Housing | HDF closed, reinforced construction |
| Amplifier | Class D 1000W RMS / 1500W Peak |
| Frequency response | ±10 dB: 18-300 Hz ±3 dB: 28-250 Hz |
| Low-pass filter | 30-200 Hz adjustable, 12/24/36/48 dB/octave |
| Delay | Adjustable 0-500 ms |
| Inputs | RCA Stereo / LFE XLR Stereo / LFE High level stereo |
| Outputs | RCA Stereo / LFE XLR Stereo / LFE |
| Cover | Black fabric grille, MDF frame |
| Auto power-on | Yes, sensitivity adjustable |
| Power switch | Auto / Trigger / On |
| Voltage | 115V – 230V |
| Dimensions (WxHxD) | 360 x 340 x 440 mm |
| Weight | 30 kg |
| Shipping weight | 33 kg |
| Woofer | 12″ high-performance driver, basket with three ventilation channels, carbon fiber cone, dual-spider Four-layer 4″/102mm voice coil Triple ferrite magnet system |
|---|---|
| Housing | HDF closed, reinforced construction |
| Amplifier | Class D 1200W RMS / 1700W Peak |
| Frequency response | ±10 dB: 15-280 Hz ±3 dB: 25-200 Hz |
| Low-pass filter | 30-200 Hz adjustable, 12/24/36/48 dB/octave |
| Delay | Adjustable 0-500 ms |
| Inputs | RCA Stereo / LFE XLR Stereo / LFE High level stereo |
| Outputs | RCA Stereo / LFE XLR Stereo / LFE |
| Cover | Black fabric grille, MDF frame |
| Auto power-on | Yes, sensitivity adjustable |
| Power switch | On / Auto / Trigger |
| Voltage | 115V – 230V |
| Dimensions (WxHxD) | 380 x 400 x 480 mm |
| Weight | 35 kg |
| Shipping weight | 40 kg |
| Woofer | 15″ high-performance driver, basket with three ventilation channels, carbon fiber cone, dual-spider Four-layer 4″/102mm voice coil Triple ferrite magnet system |
|---|---|
| Housing | HDF closed, reinforced construction |
| Amplifier | Class D 1500W RMS / 2000W Peak |
| Frequency response | ±10 dB: 15-250 Hz ±3 dB: 22-180 Hz |
| Low-pass filter | 30-200 Hz adjustable, 12/24/36/48 dB/octave |
| Delay | Adjustable 0-500 ms |
| Inputs | RCA Stereo / LFE XLR Stereo / LFE High level stereo |
| Outputs | RCA Stereo / LFE XLR Stereo / LFE |
| Cover | Black fabric grille, MDF frame |
| Auto power-on | Yes, sensitivity adjustable |
| Power switch | On / Auto / Trigger |
| Voltage | 115V – 230V |
| Dimensions (WxHxD) | 470 x 470 x 580 mm |
| Weight | 45 kg |
| Shipping weight | 50 kg |
| Woofer | 18″ high-performance driver, basket with three ventilation channels, carbon fiber cone, dual-spider Four-layer 4″/102mm voice coil Triple ferrite magnet system |
|---|---|
| Housing | HDF closed, reinforced construction |
| Amplifier | Class D 1800W RMS / 2500W Peak |
| Frequency response | ±10 dB: 13-220 Hz ±3 dB: 20-180 Hz |
| Low-pass filter | 30-200 Hz adjustable, 12/24/36/48 dB/octave |
| Delay | Adjustable 0-500 ms |
| Inputs | RCA Stereo / LFE XLR Stereo / LFE High level stereo |
| Outputs | RCA Stereo / LFE XLR Stereo / LFE |
| Cover | Black fabric grille, MDF frame |
| Auto power-on | Yes, sensitivity adjustable |
| Power switch | On / Auto / Trigger |
| Voltage | 115V – 230V |
| Dimensions (WxHxD) | 550 x 560 x 620 mm |
| Weight | 55 kg |
| Shipping weight | 62 kg |
